Molytech plastic modular conveyor belts are specifically designed for conveying and processing applications in the food, beverage, baking, fruit and vegetable, canning, and pharmaceutical industries. The conveyor belt is assembled from modular chain links, featuring positive drive, anti-skid, easy maintenance, and supporting straight movement, side bending, incline, cleaning and drainage, cooling and drying, and accumulation and diversion under various working conditions. With our own mold and manufacturing capabilities, we provide compatible size, quick replacement, and reliable delivery solutions for conveyor belts.

Applicable Industries

• Beverage and Beer: Bottle/can transfer after cleaning, diversion/merging, and buffer accumulation
• Food and Baking: Cooling, drying, powder/coating sections, transfer before and after packaging
• Meat, Poultry, Seafood and Fruit & Vegetable Processing: Cleaning, grading, water drainage, and quick change cleaning
• Canned Goods and Metal Components: Wear-resistant, low noise, and stable conveying
• Pharmaceutical and Cosmetics: Small item handling, inspection, and packaging in clean environments

Common Structures and Series (Examples)

• Flat Top: Smooth surface, suitable for conveying boxes, trays, bags, and small items
• Flush/Perforated Grid: Good drainage, ventilation, and cooling
• Raised Rib: Reduced contact area, facilitating turning and drying
• Roller/Low Back Pressure: Suitable for high-speed accumulation and sorting
• Friction Top/Rubber Top: For incline, positioning, and anti-slip purposes
• Flights/Cleats: Multiple heights available, used for incline and spacing conveying
• Sidewalls/Side Guards: Prevent scattering and increase load stability
• Small Transfer Solutions (Nosebar Friendly): Supports small diameter nosebar transfer, suitable for small item handling
• Side-Flex Conveyor Belt (Radius/Side-Flex): Used for curved or "S" shaped layouts, with corresponding chain wheels and chain pressing devices

Note: The above are common structures; more configurations can be selected or customized based on project requirements.

Material and Performance Options

• Belt Material: PP (lightweight, chemical-resistant, preferred for wet areas), PE (low-temperature flexibility, suitable for cold storage), POM/Acetal (high rigidity, wear-resistant, suitable for dry areas and fixed positioning), PA Nylon (wear-resistant and heat-resistant requirements)
• Pin Shaft Material: POM engineering plastic or stainless steel (304/316), selected based on temperature, strength, and cleaning requirements
• Special Functions: Anti-static, conductive static, metal/beam detection, flame retardant, anti-staining, blue food visualization, low friction or high friction formulations
• Food Compliance: Optional food contact material compliance declaration can be provided upon request (e.g., FDA, EU 10/2011, etc.)

Specification Parameters (Examples)

• Common Pitch: 8 mm, 12.7 mm, 25.4 mm, 50.8 mm, etc.
• Width Increments: Common increments of 10 mm or 12.5 mm, customizable width supported
• Hole Ratio: 0% (fully enclosed) to approximately 50% (high drainage/ventilation) with multiple options available
• Operating Temperature: Approximately -40°C to +90°C (depending on material and cleaning conditions)
• Nosebar Diameter: Small pitch series can accommodate nosebar diameter of approximately 10-18 mm (subject to specific model)
• Allowable Tension/Speed: Selection based on series, width, and working conditions, with engineer-provided verification and safety factor

Quality and Delivery

• In-house mold, injection molding, and processing, with process quality control and batch traceability, ensuring high consistency for repeat orders
• Engineer-assisted technical screening and prototype verification, supporting OEM/ODM, color, and logo customization
• Support for small batch production and expedited delivery, complete export documentation and global logistics

Why Choose Molytech

• 10+ years of experience in modular conveyor belt and conveying component manufacturing and selection
• Size compatibility and quick replacement, reducing downtime and maintenance time
• Selection and verification centered on engineering, ensuring stability, cleanliness, and high efficiency

Get Quotation and Sample

Please send our engineering team your working conditions parameters (product type/weight, speed, belt width, conveying layout, temperature and chemical medium, delivery requirements). We will provide product selection suggestions, sample plans, and delivery schedules within 24-48 hours.
